| MODEL |
NORAX-DTS-250 |
NORAX-DTS-150 |
| LASER Source |
Nd: YAG (Flash Lamp Pumped) |
Nd: YAG (Flash Lamp Pumped) |
| Wavelength |
1064 nm |
1064 nm |
| Average Output Power |
Up to 250 W |
Up to 150 W |
| Pulse Energy |
Max. 250J @ 1Hz |
Max. 150J @ 1Hz |
| Peak Power |
12.5 kW |
7.5 kW |
| Pulse Frequency |
up to 30 Hz |
up to 10 Hz |
| Pulse Duration |
0.1-20 ms |
0.1-20 ms |
| Spot Diameter |
0.15-3 mm |
0.15-3 mm |
| Operating Mode |
Pulsed |
Pulsed |
| Beam Quality Factor (M²) |
M² <2 |
M² <3.5 |
| Control Interface |
10" Full-Color Touchscreen Joystick |
10" Full-Color Touchscreen Joystick |
| Integrated Vision System |
High-Resolution CCD and Full- Color Display 10X Stereo Microscope |
High-Resolution CCD and Full- Color Display 10X Stereo Microscope |
| Power Requirements |
1-Ph, 220/230 VAC, 50/60 Hz, 25A |
1-Ph, 220/230 VAC, 50/60 Hz, 25A |
| Cooling System |
Internal Chiller Unit |
Internal Chiller Unit |
| Machine Dimensions (L × W × H) |
854 × 543 × 442 mm |
854 × 543 × 442 mm |
| Net Weight |
51 kg |
51 kg |
